Image is for reference only , See Product Specifications
DMC4029SK4-13
| Manufacturers: | Diodes Incorporated |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Arrays |
| Data Sheet: | DMC4029SK4-13 |
| Description: | MOSFET N/P-CH 40V 8.3A TO252 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Diodes Incorporated |
| Product Category | Transistors - FETs, MOSFETs - Arrays |
| Series | - |
| FET Type | N and P-Channel Complementary |
| Packaging | Tape & Reel (TR) |
| FET Feature | Standard |
| Part Status | Active |
| Power - Max | 1.5W |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-5, DPak (4 Leads + Tab), TO-252AD |
| Vgs(th) (Max) @ Id | 3V @ 250µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 24mOhm @ 6A, 10V |
| Supplier Device Package | TO-252-4L |
| Gate Charge (Qg) (Max) @ Vgs | 19.1nC @ 20V |
| Drain to Source Voltage (Vdss) | 40V |
| Input Capacitance (Ciss) (Max) @ Vds | 1060pF @ 20V |
| Current - Continuous Drain (Id) @ 25°C | 8.3A |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.23 | $0.23 | $0.22 |
