Image is for reference only , See Product Specifications
ASB03505MA-AF00
| Manufacturers: | Delta Electronics |
|---|---|
| Product Category: | DC Brushless Fans (BLDC) |
| Data Sheet: | ASB03505MA-AF00 |
| Description: | FAN 5VDC 35MMX10MM TACH |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Delta Electronics |
| Product Category | DC Brushless Fans (BLDC) |
| RPM | 5800 RPM |
| Noise | 18.5 dB(A) |
| Width | 10.00mm |
| Series | ASB |
| Weight | 0.022 lb (9.98 g) |
| Air Flow | 4.5 CFM (0.126m³/min) |
| Fan Type | Tubeaxial |
| Features | Speed Sensor (Tach) |
| Approvals | CE, cURus, VDE |
| Part Status | Active |
| Termination | 3 Wire Leads |
| Bearing Type | Sleeve |
| Power (Watts) | 400mW |
| Voltage Range | 4.5 ~ 5.5VDC |
| Static Pressure | 0.079 in H2O (19.6 Pa) |
| Voltage - Rated | 5VDC |
| Lifetime @ Temp. | - |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Size / Dimension | Square - 35mm L x 35mm H |
| Ingress Protection | - |
| Current Rating (Amps) | 0.080A |
| Operating Temperature | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.29 | $4.20 | $4.12 |
