Image is for reference only , See Product Specifications
AFB0824L-F00
| Manufacturers: | Delta Electronics |
|---|---|
| Product Category: | DC Brushless Fans (BLDC) |
| Data Sheet: | AFB0824L-F00 |
| Description: | 80X80X25MM 24V DC FAN W/SPEED SE |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Delta Electronics |
| Product Category | DC Brushless Fans (BLDC) |
| RPM | 2400 RPM |
| Noise | 25.0 dB(A) |
| Width | 25.40mm |
| Series | AFB |
| Weight | 0.176 lb (80.00 g) |
| Air Flow | 27.9 CFM (0.781m³/min) |
| Fan Type | Tubeaxial |
| Features | Locked Rotor Protection, Speed Sensor (Tach) |
| Approvals | CE, CSA, UR, VDE |
| Part Status | Active |
| Termination | 3 Wire Leads |
| Bearing Type | Ball |
| Power (Watts) | 1.20W |
| Voltage Range | 14 ~ 27.6VDC |
| Static Pressure | 0.102 in H2O (25.5 Pa) |
| Voltage - Rated | 24VDC |
| Lifetime @ Temp. | 70000 Hrs @ 40°C |
| Material - Blade | Plastic |
| Material - Frame | Plastic |
| Size / Dimension | Square - 80mm L x 80mm H |
| Ingress Protection | - |
| Current Rating (Amps) | 0.050A |
| Operating Temperature | - |
In Stock 129 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $13.69 | $13.42 | $13.15 |
