CT10-1540-G2
| Manufacturers: | Coto Technology |
|---|---|
| Product Category: | Magnetic, Reed Switches |
| Data Sheet: | CT10-1540-G2 |
| Description: | SWITCH REED SPST-NO 250MA 100V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Coto Technology |
| Product Category | Magnetic, Reed Switches |
| Type | Molded Body |
| Series | CT10 |
| Circuit | SPST-NO |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Size - Body | 0.458" L x 0.095" W x 0.115" H (11.63mm x 2.41mm x 2.92mm) |
| Mounting Type | Surface Mount |
| Operate Range | 15 ~ 40AT |
| Power - Rated | 10W |
| Release Range | - |
| Current - Carry | 500mA (DC) |
| Length - Overall | 0.770" (19.56mm) |
| Termination Style | Gull Wing |
| Height Above Board | 0.115" (2.92mm) |
| Current - Switching | 500mA (AC/DC) |
| Operating Temperature | -40°C ~ 125°C |
| Voltage - Switching AC | 140V |
| Voltage - Switching DC | 200V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.64 | $0.63 | $0.61 |
