Image is for reference only , See Product Specifications
2268.2
| Manufacturers: | Conta-Clip, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | 2268.2 |
| Description: | 5MM,FEEDTHRU(3)LVLTB;Q VERSION |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Conta-Clip, Inc. |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Beige |
| Series | IK |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Voltage - UL | - |
| Current - IEC | 24A |
| Voltage - IEC | 250V |
| Disconnect Type | - |
| Number of Levels | 3 |
| Stripping Length | 7mm |
| Terminal - Width | 5.0mm |
| Termination Style | Screw |
| Number of Positions | 6 |
| Material - Insulation | Polyamide (PA66), Nylon 6/6 |
| Wire Gauge or Range - AWG | 14-22 AWG |
| Wire Gauge or Range - mm² | 0.2-4mm² |
| Material Flammability Rating | UL94 V-2 |
In Stock 100 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.58 | $6.45 | $6.32 |
