Image is for reference only , See Product Specifications
EC4A11H
| Manufacturers: | Cincon Electronics Co. LTD |
|---|---|
| Product Category: | DC DC Converters |
| Data Sheet: | EC4A11H |
| Description: | ISOLATED DC/DC CONVERTERS 5-6W 1 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Cincon Electronics Co. LTD |
| Product Category | DC DC Converters |
| Type | Isolated Module |
| Series | EC4A (6W) |
| Features | SCP |
| Efficiency | 80% |
| Part Status | Active |
| Applications | ITE (Commercial) |
| Mounting Type | Through Hole |
| Power (Watts) | 5W |
| Package / Case | 24-DIP Module, 14 Leads |
| Control Features | - |
| Size / Dimension | 1.25" L x 0.80" W x 0.40" H (31.8mm x 20.3mm x 10.2mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Isolation | 3kV |
| Operating Temperature | -25°C ~ 71°C |
| Voltage - Input (Max) | 36V |
| Voltage - Input (Min) | 18V |
| Current - Output (Max) | 1A |
| Supplier Device Package | - |
In Stock 447 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $12.72 | $12.47 | $12.22 |
