Image is for reference only , See Product Specifications
PL155ACFL-201
| Manufacturers: | Cinch Connectivity Solutions Trompeter |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | PL155ACFL-201 |
| Description: | CONN TRS PLUG STR CRIMP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Cinch Connectivity Solutions Trompeter |
| Product Category | Coaxial Connectors (RF) |
| Series | 150 |
| Features | Four Lug |
| Includes | 2 pcs - 1 Connector, 1 Heat Shrink |
| Impedance | Non-Constant |
| Packaging | Bulk |
| Body Finish | Nickel |
| Cable Group | M17/176-00002 |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug, Male Pin (Concentric) |
| Fastening Type | Bayonet Lock |
| Insertion Loss | - |
| Voltage Rating | 400V |
| Connector Style | TRS, Twinaxial/Triaxial |
| Frequency - Max | 500MHz |
| Number of Ports | 1 |
| Mounting Feature | - |
| Ingress Protection | - |
| Shield Termination | Crimp |
| Contact Termination | Crimp |
| Dielectric Material | - |
| Operating Temperature | -65°C ~ 200°C |
| Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper |
In Stock 9 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $27.44 | $26.89 | $26.35 |
