Image is for reference only , See Product Specifications
131-6701-346
| Manufacturers: | Cinch Connectivity Solutions Johnson |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | 131-6701-346 |
| Description: | CONN SMC JACK R/A 50OHM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Cinch Connectivity Solutions Johnson |
| Product Category | Coaxial Connectors (RF) |
| Series | - |
| Features | - |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Impedance | 50Ohm |
| Packaging | Bulk |
| Body Finish | Nickel |
| Cable Group | - |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Panel Mount, Through Hole, Right Angle |
| Connector Type | Jack, Male Pin |
| Fastening Type | Threaded |
| Insertion Loss | - |
| Voltage Rating | 335V |
| Connector Style | SMC |
| Frequency - Max | 10GHz |
| Number of Ports | 1 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | - |
| Shield Termination | Solder |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -65°C ~ 165°C |
| Center Contact Plating | Gold |
| Center Contact Material | Brass |
In Stock 77 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $11.48 | $11.25 | $11.03 |
