Image is for reference only , See Product Specifications
TBP01R2W-508-10BE
| Manufacturers: | CUI, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | TBP01R2W-508-10BE |
| Description: | TERMINAL BLOCK, PLUGGABLE, W SCR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | CUI, Inc. |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Color | Blue |
| Pitch | 0.200" (5.08mm) |
| Series | TBP01R2W-508 |
| Features | Mating Flange |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 16A |
| Voltage - UL | 300V |
| Current - IEC | 20A |
| Mounting Type | Through Hole |
| Voltage - IEC | 320V |
| Torque - Screw | - |
| Plug Wire Entry | - |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.472" (12.00mm) |
| Termination Style | Solder |
| Wire Strip Length | - |
| Header Orientation | Vertical |
| Ingress Protection | - |
| Contact Tail Length | 0.157" (4.00mm) |
| Dielectric Material | Polyamide (PA66), Nylon 6/6 |
| Number of Positions | 10 |
| Positions Per Level | 10 |
| Contact Mating Finish | Tin |
| Operating Temperature | -40°C ~ 105°C |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 598 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.35 | $1.32 | $1.30 |
