Image is for reference only , See Product Specifications
TBP01P1-508-05BE
| Manufacturers: | CUI, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | TBP01P1-508-05BE |
| Description: | TERMINAL BLOCK, PLUGGABLE, 5.08 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | CUI, Inc. |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Blue |
| Pitch | 0.200" (5.08mm) |
| Series | TBP01P1-508 |
| Features | Retention Latches (Non-Wire Side) |
| Packaging | Bulk |
| Screw Size | M3 |
| Part Status | Active |
| Current - UL | 16A |
| Voltage - UL | 300V |
| Current - IEC | 20A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 320V |
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
| Plug Wire Entry | 180° |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.591" (15.00mm) |
| Termination Style | Screw - Rising Cage Clamp |
| Wire Strip Length | 7mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyamide (PA66), Nylon 6/6 |
| Number of Positions | 5 |
| Positions Per Level | 5 |
| Contact Mating Finish | Nickel |
| Operating Temperature | -40°C ~ 105°C |
| Wire Gauge or Range - AWG | 12-28 AWG |
| Wire Gauge or Range - mm² | 2.5mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 599 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.46 | $1.43 | $1.40 |
