| Manufacturer |
CUI, Inc. |
| Product Category |
Barrel - Audio Connectors |
| Gender |
Female |
| Series |
- |
| Features |
Board Lock |
| Includes |
- |
| Packaging |
Bulk |
| Shielding |
Shielded |
| Body Color |
Black |
| Part Status |
Obsolete |
| Termination |
Solder |
| Thread Size |
- |
| Signal Lines |
Stereo (3 Conductor, TRS) |
| Body Material |
- |
| Cable Opening |
- |
| Mounting Type |
Through Hole, Right Angle |
| Connector Type |
Phone Jack, Dual |
| Actual Diameter |
0.142" (3.60mm) |
| Panel Hole Size |
- |
| Voltage - Rated |
16VDC |
| Contact Material |
Copper Alloy |
| Insulation Color |
- |
| Internal Switch(s) |
Does Not Contain Switch |
| Dielectric Material |
Polyamide (PA66), Nylon 6/6 |
| Mating Length/Depth |
- |
| Current Rating (Amps) |
300mA |
| Operating Temperature |
-25°C ~ 85°C |
| Contact Material - Plating |
Tin |
| Number of Positions/Contacts |
2 Sets of 3 Conductors, 6 Contacts |
| Industry Recognized Mating Diameter |
3.50mm (0.141", 1/8", Mini Plug) - Headphone |
