| Manufacturer |
CUI, Inc. |
| Product Category |
Barrel - Audio Connectors |
| Gender |
Female |
| Series |
SJ1 |
| Features |
Board Guide |
| Includes |
- |
| Packaging |
Bulk |
| Shielding |
Unshielded |
| Body Color |
Black |
| Part Status |
Active |
| Termination |
Solder |
| Thread Size |
- |
| Signal Lines |
Stereo (4 Conductor, TRRS) |
| Body Material |
- |
| Cable Opening |
- |
| Mounting Type |
Through Hole, Right Angle |
| Connector Type |
Phone Jack |
| Actual Diameter |
0.102" (2.60mm) |
| Panel Hole Size |
- |
| Voltage - Rated |
16VDC |
| Contact Material |
Brass; Copper Alloy |
| Insulation Color |
- |
| Internal Switch(s) |
Single Switch |
| Dielectric Material |
Polyamide (PA66), Nylon 6/6 |
| Mating Length/Depth |
0.433" (11.00mm) |
| Current Rating (Amps) |
300mA |
| Operating Temperature |
-25°C ~ 85°C |
| Contact Material - Plating |
Gold |
| Number of Positions/Contacts |
4 Conductors, 5 Contacts |
| Industry Recognized Mating Diameter |
2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone |
