Image is for reference only , See Product Specifications
MD-40S
| Manufacturers: | CUI, Inc. |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | MD-40S |
| Description: | CONN RCPT FMALE MINI DIN 4P SLDR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | CUI, Inc. |
| Product Category | Circular Connectors |
| Color | Black |
| Series | MD-S |
| Features | Board Lock, Ground |
| Packaging | Tray |
| Shielding | Unshielded |
| Orientation | Keyed |
| Part Status | Active |
| Termination | Solder |
| Applications | - |
| Shell Finish | - |
| Cable Opening | - |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Receptacle, Female Sockets |
| Fastening Type | Push-Pull |
| Shell Material | Polybutylene Terephthalate (PBT) |
| Voltage Rating | 100VAC, 12VDC |
| Insert Material | - |
| Shell Size, MIL | - |
| Contact Material | Phosphor Bronze |
| Mounting Feature | - |
| Ingress Protection | - |
| Number of Positions | 4 |
| Shell Size - Insert | Mini DIN |
| Current Rating (Amps) | 1A, 2A |
| Operating Temperature | -40°C ~ 85°C |
| Contact Finish - Mating | Silver |
| Backshell Material, Plating | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | - |
In Stock 5693 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.39 | $1.36 | $1.33 |
