Image is for reference only , See Product Specifications
209-5MS
| Manufacturers: | CTS Electrocomponents |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | 209-5MS |
| Description: | SWITCH SLIDE DIP SPST 100MA 20V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | CTS Electrocomponents |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.558" (14.17mm) |
| Series | 209 |
| Circuit | SPST |
| Features | Epoxy Sealed Terminals |
| Washable | No |
| Packaging | Tube |
| Part Status | Active |
| Actuator Type | Slide (Standard) |
| Body Material | - |
| Mounting Type | Through Hole |
| Actuator Level | Raised |
| Contact Finish | Gold |
| Voltage Rating | 20VDC |
| Electrical Life | 2,000 Cycles |
| Mechanical Life | - |
| Contact Material | Beryllium Copper |
| Termination Style | PC Pin |
| Height Above Board | 0.190" (4.83mm) |
| Number of Positions | 5 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -40°C ~ 85°C |
In Stock 1129 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.77 | $0.75 | $0.74 |
