241A16510X
| Manufacturers: | CONEC |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 241A16510X |
| Description: | CONN D-SUB HD PLUG 26P VERT SLDR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | CONEC |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | 241A |
| Features | Filter, Grounding Indents |
| Packaging | Bulk |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | Machined |
| Contact Type | Signal |
| Mounting Type | Through Hole |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Board Side (4-40) |
| Number of Rows | 3 |
| Voltage Rating | 100V |
| Backset Spacing | - |
| Connector Style | D-Sub, High Density |
| Contact Material | Copper Alloy |
| Ingress Protection | IP20 |
| Dielectric Material | Thermoplastic |
| Number of Positions | 26 |
| Current Rating (Amps) | 3A |
| Operating Temperature | -25°C ~ 85°C |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish Thickness | 8.00µin (0.203µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 2 (DA, A) High Density |
In Stock 24 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $28.55 | $27.98 | $27.42 |
