Image is for reference only , See Product Specifications
164A17159X
| Manufacturers: | CONEC |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 164A17159X |
| Description: | CONN D-SUB HD RCPT 15P VERT SLDR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | CONEC |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | 164A |
| Features | - |
| Packaging | - |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | Machined |
| Contact Type | Signal |
| Mounting Type | Through Hole |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 3 |
| Voltage Rating | 60V |
| Backset Spacing | - |
| Connector Style | D-Sub, High Density |
| Contact Material | Copper Alloy |
| Ingress Protection | IP20 |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Number of Positions | 15 |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 125°C |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish Thickness | - |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 1 (DE, E) High Density |
In Stock 48 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.20 | $7.06 | $6.91 |
Request Quote
