SPA04AB
| Manufacturers: | C&K |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | SPA04AB |
| Description: | SWITCH SLIDE DIP SPST 10MA 20V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | C&K |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.542" (13.77mm) |
| Series | SPA |
| Circuit | SPST |
| Features | - |
| Washable | Yes |
| Packaging | Tube |
| Part Status | Active |
| Actuator Type | Slide (Standard) |
| Body Material | Polyphenylene Sulfide (PPS) |
| Mounting Type | Through Hole, Right Angle |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 20VDC |
| Electrical Life | 1,000 Cycles |
| Mechanical Life | 1,000 Cycles |
| Contact Material | Beryllium Copper |
| Termination Style | PC Pin |
| Height Above Board | 0.169" (4.30mm) |
| Number of Positions | 4 |
| Current Rating (Amps) | 10mA |
| Operating Temperature | -30°C ~ 60°C |
In Stock 8559 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.76 | $3.68 | $3.61 |
