Image is for reference only , See Product Specifications
BD06AV
| Manufacturers: | C&K |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | BD06AV |
| Description: | SWITCH SLIDE DIP SPST 100MA 5V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | C&K |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.680" (17.27mm) |
| Series | BD |
| Circuit | SPST |
| Features | - |
| Washable | Yes |
| Packaging | Tube |
| Part Status | Active |
| Actuator Type | Slide (Standard) |
| Body Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Mounting Type | Through Hole, Right Angle |
| Actuator Level | Raised |
| Contact Finish | Gold |
| Voltage Rating | 5VDC |
| Electrical Life | 10,000 Cycles |
| Mechanical Life | 10,000 Cycles |
| Contact Material | Phosphor Bronze |
| Termination Style | PC Pin |
| Height Above Board | 0.380" (9.64mm) |
| Number of Positions | 6 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -40°C ~ 85°C |
In Stock 2222 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.12 | $3.06 | $3.00 |
