PX0730/P
| Manufacturers: | Bulgin |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | PX0730/P |
| Description: | CONN RCPT MALE 3POS SCREW |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bulgin |
| Product Category | Circular Connectors |
| Color | Black |
| Series | Buccaneer®, Standard |
| Features | - |
| Packaging | Bulk |
| Shielding | Unshielded |
| Orientation | Keyed |
| Part Status | Active |
| Termination | Screw |
| Applications | - |
| Shell Finish | - |
| Cable Opening | - |
| Mounting Type | Panel Mount |
| Connector Type | Receptacle, Male Pins |
| Fastening Type | Threaded |
| Shell Material | Polyamide (PA), Nylon, Glass Filled |
| Voltage Rating | 277VAC/DC |
| Insert Material | Polyamide (PA), Nylon |
| Shell Size, MIL | - |
| Contact Material | Brass |
| Mounting Feature | Bulkhead - Rear Side Nut, Flange |
| Ingress Protection | IP68/69K - Dust Tight, Water Resistant, Waterproof |
| Number of Positions | 3 (2 Power + PE) |
| Shell Size - Insert | - |
| Current Rating (Amps) | 10A |
| Operating Temperature | -20°C ~ 70°C |
| Contact Finish - Mating | Nickel |
| Backshell Material, Plating | - |
| Material Flammability Rating | UL94 HB |
| Contact Finish Thickness - Mating | - |
In Stock 77 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $13.94 | $13.66 | $13.39 |
