Image is for reference only , See Product Specifications
HSMF-C144
| Manufacturers: | Broadcom Limited |
|---|---|
| Product Category: | LED Indication - Discrete |
| Data Sheet: | HSMF-C144 |
| Description: | LED GRN/RED CLEAR SMD R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Broadcom Limited |
| Product Category | LED Indication - Discrete |
| Color | Green, Red |
| Series | - |
| Features | - |
| Lens Size | 2.00mm x 1.00mm |
| Packaging | Digi-Reel® |
| Lens Color | Colorless |
| Lens Style | Rectangle with Domed Top |
| Part Status | Active |
| Height (Max) | 1.10mm |
| Configuration | Common Anode |
| Mounting Type | Surface Mount, Right Angle |
| Viewing Angle | 120° |
| Current - Test | 20mA Green, 20mA Red |
| Package / Case | 4-SMD |
| Size / Dimension | 3.00mm L x 2.00mm W |
| Lens Transparency | Clear |
| Wavelength - Peak | 571nm Green, 644nm Red |
| Millicandela Rating | 33mcd Green, 79mcd Red |
| Wavelength - Dominant | 570nm Green, 632nm Red |
| Supplier Device Package | SMD |
| Voltage - Forward (Vf) (Typ) | 2V Green, 2V Red |
In Stock 11961 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
