Image is for reference only , See Product Specifications
HCPL-6250
| Manufacturers: | Broadcom Limited |
|---|---|
| Product Category: | Optoisolators - Logic Output |
| Data Sheet: | HCPL-6250 |
| Description: | OPTOISO 1.5KV PUSH PULL 16FLATPK |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Broadcom Limited |
| Product Category | Optoisolators - Logic Output |
| Series | - |
| Data Rate | 5MBd |
| Packaging | Tube |
| Input Type | DC |
| Output Type | Push-Pull, Totem Pole |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 16-Flatpack |
| Voltage - Supply | 4.5V ~ 20V |
| Number of Channels | 4 |
| Voltage - Isolation | 1500VDC |
| Operating Temperature | -55°C ~ 125°C |
| Inputs - Side 1/Side 2 | 4/0 |
| Rise / Fall Time (Typ) | 45ns, 10ns |
| Supplier Device Package | 16-Flatpack |
| Current - Output / Channel | 15mA |
| Voltage - Forward (Vf) (Typ) | 1.3V |
| Current - DC Forward (If) (Max) | 8mA |
| Propagation Delay tpLH / tpHL (Max) | 350ns, 350ns |
| Common Mode Transient Immunity (Min) | 1kV/µs |
In Stock 32 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $153.54 | $150.47 | $147.46 |
