Image is for reference only , See Product Specifications
HCPL-5500
| Manufacturers: | Broadcom Limited |
|---|---|
| Product Category: | Optoisolators - Transistor, Photovoltaic Output |
| Data Sheet: | HCPL-5500 |
| Description: | OPTOISO 1.5KV TRANS W/BASE 8DIP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Broadcom Limited |
| Product Category | Optoisolators - Transistor, Photovoltaic Output |
| Series | - |
| Packaging | Tube |
| Input Type | DC |
| Output Type | Transistor with Base |
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Number of Channels | 1 |
| Voltage - Isolation | 1500VDC |
| Vce Saturation (Max) | - |
| Operating Temperature | -55°C ~ 125°C |
| Rise / Fall Time (Typ) | - |
| Voltage - Output (Max) | 20V |
| Supplier Device Package | 8-DIP |
| Current - Output / Channel | 8mA |
| Current Transfer Ratio (Max) | - |
| Current Transfer Ratio (Min) | 9% @ 16mA |
| Voltage - Forward (Vf) (Typ) | 1.55V |
| Turn On / Turn Off Time (Typ) | 400ns, 1µs |
| Current - DC Forward (If) (Max) | 20mA |
In Stock 122 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $66.98 | $65.64 | $64.33 |
