Image is for reference only , See Product Specifications
HCPL-0710
| Manufacturers: | Broadcom Limited |
|---|---|
| Product Category: | Optoisolators - Logic Output |
| Data Sheet: | HCPL-0710 |
| Description: | OPTOISO 3.75KV PUSH PULL 8SO |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Broadcom Limited |
| Product Category | Optoisolators - Logic Output |
| Series | - |
| Data Rate | 12.5MBd |
| Packaging | Tube |
| Input Type | Logic |
| Output Type | Push-Pull, Totem Pole |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Voltage - Supply | 4.5V ~ 5.5V |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Operating Temperature | -40°C ~ 100°C |
| Inputs - Side 1/Side 2 | 1/0 |
| Rise / Fall Time (Typ) | 13ns, 5ns |
| Supplier Device Package | 8-SO Tall |
| Current - Output / Channel | 10mA |
| Voltage - Forward (Vf) (Typ) | - |
| Current - DC Forward (If) (Max) | - |
| Propagation Delay tpLH / tpHL (Max) | 40ns, 40ns |
| Common Mode Transient Immunity (Min) | 10kV/µs |
In Stock 2432 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.48 | $7.33 | $7.18 |
