| Manufacturer |
Broadcom Limited |
| Product Category |
LED Indication - Discrete |
| Color |
Red, Green, Blue (RGB) |
| Series |
- |
| Features |
- |
| Lens Size |
2.90mm Dia |
| Packaging |
Digi-Reel® |
| Lens Color |
Colorless |
| Lens Style |
Round with Flat Top |
| Part Status |
Obsolete |
| Height (Max) |
2.20mm |
| Configuration |
Common Anode |
| Mounting Type |
Surface Mount |
| Viewing Angle |
115° |
| Current - Test |
20mA Red, 20mA Green, 20mA Blue |
| Package / Case |
4-SMD, J-Lead |
| Base Part Number |
ASMT-QTC0 |
| Size / Dimension |
3.40mm L x 3.20mm W |
| Lens Transparency |
Clear |
| Wavelength - Peak |
629nm Red, 521nm Green, 465nm Blue |
| Millicandela Rating |
315mcd Red, 470mcd Green, 140mcd Blue |
| Wavelength - Dominant |
621nm Red, 528nm Green, 470nm Blue |
| Supplier Device Package |
4-PLCC |
| Voltage - Forward (Vf) (Typ) |
2.1V Red, 3.2V Green, 3.2V Blue |
