Image is for reference only , See Product Specifications
ACPL-M51L-000E
| Manufacturers: | Broadcom Limited |
|---|---|
| Product Category: | Optoisolators - Transistor, Photovoltaic Output |
| Data Sheet: | ACPL-M51L-000E |
| Description: | OPTOISO 3.75KV TRANS |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Broadcom Limited |
| Product Category | Optoisolators - Transistor, Photovoltaic Output |
| Series | - |
| Packaging | Bulk |
| Input Type | DC |
| Output Type | Transistor |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 6-SOIC (0.173", 4.40mm Width), 5 Leads |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Vce Saturation (Max) | - |
| Operating Temperature | -40°C ~ 105°C |
| Rise / Fall Time (Typ) | - |
| Voltage - Output (Max) | 24V |
| Supplier Device Package | 5-SO |
| Current - Output / Channel | 8mA |
| Current Transfer Ratio (Max) | 200% @ 3mA |
| Current Transfer Ratio (Min) | 80% @ 3mA |
| Voltage - Forward (Vf) (Typ) | 1.5V |
| Turn On / Turn Off Time (Typ) | 300ns, 330ns |
| Current - DC Forward (If) (Max) | 20mA |
In Stock 7289 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.33 | $2.28 | $2.24 |
