Image is for reference only , See Product Specifications
SRP3020TA-2R2M
| Manufacturers: | Bourns, Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | SRP3020TA-2R2M |
| Description: | FIXED IND 2.2UH 3.5A 75MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bourns, Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | SRP3020TA |
| Ratings | AEC-Q200 |
| Features | - |
| Q @ Freq | 10 @ 100kHz |
| Packaging | Digi-Reel® |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 2.2µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD |
| Material - Core | Carbonyl Powder |
| Base Part Number | SRP3020TA |
| Size / Dimension | 0.138" L x 0.126" W (3.50mm x 3.20mm) |
| DC Resistance (DCR) | 75mOhm Max |
| Current - Saturation | 3.7A |
| Current Rating (Amps) | 3.5A |
| Height - Seated (Max) | 0.079" (2.00mm) |
| Operating Temperature | -40°C ~ 150°C |
| Supplier Device Package | 2-SMD |
| Frequency - Self Resonant | 45MHz |
| Inductance Frequency - Test | 100kHz |
In Stock 8896 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
