Image is for reference only , See Product Specifications
SDR0503-101KL
| Manufacturers: | Bourns, Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | SDR0503-101KL |
| Description: | FIXED IND 100UH 400MA 1.6 OHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bourns, Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | SDR0503 |
| Ratings | - |
| Q @ Freq | 40 @ 796kHz |
| Packaging | Cut Tape (CT) |
| Shielding | Unshielded |
| Tolerance | ±10% |
| Inductance | 100µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Base Part Number | SDR0503 |
| Size / Dimension | 0.197" L x 0.189" W (5.00mm x 4.80mm) |
| DC Resistance (DCR) | 1.6Ohm Max |
| Current - Saturation | 480mA |
| Current Rating (Amps) | 400mA |
| Height - Seated (Max) | 0.130" (3.30mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 9MHz |
| Inductance Frequency - Test | 1kHz |
In Stock 12219 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.64 | $0.63 | $0.61 |
