PM7232S-R22M-RC
| Manufacturers: | Bourns, Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | PM7232S-R22M-RC |
| Description: | FIXED IND 220NH 23A 2.8 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bourns, Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | PM7232S |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Tape & Reel (TR) |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 220nH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Iron |
| Base Part Number | PM7232S |
| Size / Dimension | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
| DC Resistance (DCR) | 2.8mOhm Max |
| Current - Saturation | 36A |
| Current Rating (Amps) | 23A |
| Height - Seated (Max) | 0.126" (3.20mm) |
| Operating Temperature | -55°C ~ 150°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 100kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.05 | $1.03 | $1.01 |
