Image is for reference only , See Product Specifications
MF-USHT050KX-2
| Manufacturers: | Bourns, Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | MF-USHT050KX-2 |
| Description: | PTC RESET FUSE 30V 500MA 1210 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bourns, Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | Multifuse®, MF-USHT |
| Ratings | AEC-Q200 |
| Approvals | cURus |
| Packaging | Digi-Reel® |
| Part Status | Active |
| Lead Spacing | - |
| Time to Trip | 100ms |
| Current - Max | 20A |
| Mounting Type | Surface Mount |
| Voltage - Max | 30V |
| Package / Case | 1210 (3225 Metric), Concave |
| Thickness (Max) | 0.033" (0.85mm) |
| Base Part Number | MF-USHT |
| Size / Dimension | 0.126" L x 0.100" W (3.20mm x 2.55mm) |
| Current - Trip (It) | 2.5A |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 125°C |
| Current - Hold (Ih) (Max) | 500mA |
| Resistance - Initial (Ri) (Min) | 300 mOhms |
| Resistance - Post Trip (R1) (Max) | 1.6 Ohms |
In Stock 10585 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
