83318E 009100
| Manufacturers: | Belden Inc. |
|---|---|
| Product Category: | Multiple Conductor Cables |
| Data Sheet: | 83318E 009100 |
| Description: | CABLE 2 COND 24AWG SHLD 100' |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Belden Inc. |
| Product Category | Multiple Conductor Cables |
| Usage | - |
| Length | 100.0' (30.5m) |
| Series | - |
| Ratings | - |
| Features | - |
| Cable Type | Multi-Conductor |
| Wire Gauge | 24 AWG |
| Part Status | Active |
| Shield Type | Braid |
| Jacket Color | White |
| Shield Coverage | 85% |
| Shield Material | Copper, Silver Coated |
| Conductor Strand | 19/36 |
| Conductor Material | Copper, Silver Coated |
| Conductor Insulation | Fluorinated Ethylene-Propylene (FEP) |
| Number of Conductors | 2 |
| Operating Temperature | -65°C ~ 200°C |
| Jacket (Insulation) Diameter | 0.131" (3.33mm) |
| Jacket (Insulation) Material | Tetrafluoroethylene (TFE) |
| Jacket (Insulation) Thickness | 0.0110" (0.279mm) |
In Stock 14 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $483.09 | $473.43 | $463.96 |
