Image is for reference only , See Product Specifications
1371P N3U500
| Manufacturers: | Belden Inc. |
|---|---|
| Product Category: | Coaxial Cables (RF) |
| Data Sheet: | 1371P N3U500 |
| Description: | COAX RG59 23AWG 75OHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Belden Inc. |
| Product Category | Coaxial Cables (RF) |
| Usage | Analog Video |
| Length | 500.0' (152.40m) |
| Series | - |
| Features | - |
| Impedance | 75 Ohms |
| Cable Type | Coaxial - Plenum |
| Wire Gauge | 23 AWG |
| Cable Group | RG-59 Mini |
| Part Status | Active |
| Shield Type | Foil, Braid |
| Jacket Color | Green |
| Shield Coverage | 100%, 85% |
| Shield Material | Aluminum; Copper, Tinned |
| Conductor Strand | Solid |
| Conductor Material | Copper, Bare |
| Dielectric Diameter | 0.102" (2.59mm) |
| Dielectric Material | Foam Fluorinated Ethylene Propylene (FFEP) |
| Operating Temperature | -20°C ~ 75°C |
| Jacket (Insulation) Diameter | 0.160" (4.06mm) |
| Jacket (Insulation) Material | Low Smoke Poly-Vinyl Chloride (LSPVC) |
| VoP, Velocity of Propagation | 80 |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $354.15 | $347.07 | $340.13 |
