Image is for reference only , See Product Specifications
0ZCF0260AF2C
| Manufacturers: | Bel Fuse, Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | 0ZCF0260AF2C |
| Description: | PTC RESET FUSE 24V 2.6A 2920 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Bel Fuse, Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | 0ZCF |
| Ratings | - |
| Approvals | cURus, TUV |
| Packaging | Digi-Reel® |
| Part Status | Active |
| Lead Spacing | - |
| Time to Trip | 20s |
| Current - Max | 100A |
| Mounting Type | Surface Mount |
| Voltage - Max | 24V |
| Package / Case | 2920 (7351 Metric), Concave |
| Thickness (Max) | 0.067" (1.70mm) |
| Size / Dimension | 0.290" L x 0.202" W (7.36mm x 5.12mm) |
| Current - Trip (It) | 5.2A |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 2.6A |
| Resistance - Initial (Ri) (Min) | 20 mOhms |
| Resistance - Post Trip (R1) (Max) | 75 mOhms |
In Stock 50 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
