Image is for reference only , See Product Specifications
08-6822-90C
| Manufacturers: | Aries Electronics |
|---|---|
| Product Category: | Sockets for ICs, Transistors |
| Data Sheet: | 08-6822-90C |
| Description: | CONN IC DIP SOCKET 8POS GOLD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Aries Electronics |
| Product Category | Sockets for ICs, Transistors |
| Type | DIP, 0.6" (15.24mm) Row Spacing |
| Series | Vertisockets™ 800 |
| Features | Closed Frame |
| Packaging | Bulk |
| Part Status | Active |
| Termination | Solder |
| Pitch - Post | 0.100" (2.54mm) |
| Mounting Type | Through Hole, Right Angle, Horizontal |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Resistance | - |
| Dielectric Material | Polyamide (PA46), Nylon 4/6, Glass Filled |
| Contact Finish - Post | Tin |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 105°C |
| Contact Finish - Mating | Gold |
| Contact Material - Post | Brass |
| Termination Post Length | 0.140" (3.56mm) |
| Contact Material - Mating | Beryllium Copper |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Number of Positions or Pins (Grid) | 8 (2 x 4) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.35 | $5.24 | $5.14 |
