Image is for reference only , See Product Specifications
901-10119
| Manufacturers: | Amphenol RF Division |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | 901-10119 |
| Description: | CONN SMA JACK STR 50 OHM SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol RF Division |
| Product Category | Coaxial Connectors (RF) |
| Series | - |
| Features | - |
| Includes | 6 pcs - 1 Connector, 1 Bushing, 1 Contact, 1 Ferrule, 1 Nut, 1 Sleeve |
| Impedance | 50Ohm |
| Packaging | Bulk |
| Body Finish | Gold |
| Cable Group | 1.13mm Coaxial Cable |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Gold |
| Mating Cycles | 500 |
| Mounting Type | Panel Mount |
| Connector Type | Jack, Female Socket |
| Fastening Type | Threaded |
| Insertion Loss | - |
| Connector Style | SMA |
| Frequency - Max | 3GHz |
| Number of Ports | 1 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | - |
| Shield Termination | Crimp |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -65°C ~ 165°C |
| Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.42 | $6.29 | $6.17 |
