Image is for reference only , See Product Specifications
034-1122-12G
| Manufacturers: | Amphenol RF Division |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | 034-1122-12G |
| Description: | CONN HD-BNC RA PLUG 12G 75 OHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol RF Division |
| Product Category | Coaxial Connectors (RF) |
| Series | - |
| Features | - |
| Includes | 3 pcs - 1 Connector, 1 End Cap, 1 Insulator |
| Impedance | 75Ohm |
| Packaging | Bulk |
| Body Finish | Nickel |
| Cable Group | Belden 1855A, 4855R |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Connector Type | Plug, Male Pin |
| Fastening Type | Bayonet Lock |
| Insertion Loss | - |
| Connector Style | BNC, HD |
| Frequency - Max | 18GHz |
| Number of Ports | 1 |
| Mounting Feature | - |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Shield Termination | Crimp |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -65°C ~ 165°C |
| Center Contact Plating | Gold |
| Center Contact Material | Phosphor Bronze |
In Stock 450 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $15.86 | $15.54 | $15.23 |
