Image is for reference only , See Product Specifications
031-5486-10RFX
| Manufacturers: | Amphenol RF Division |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | 031-5486-10RFX |
| Description: | CONN BNC RCPT R/A 50 OHM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol RF Division |
| Product Category | Coaxial Connectors (RF) |
| Series | - |
| Features | Board Lock, Isolated |
| Includes | 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut |
| Impedance | 50Ohm |
| Packaging | Tray |
| Body Finish | Nickel |
| Cable Group | - |
| Part Status | Active |
| Body Material | Zinc Die Cast |
| Housing Color | Silver, White |
| Mating Cycles | 500 |
| Mounting Type | Panel Mount, Through Hole, Right Angle |
| Connector Type | Jack, Female Socket |
| Fastening Type | Bayonet Lock |
| Insertion Loss | 0.2dB |
| Voltage Rating | 500V |
| Connector Style | BNC |
| Frequency - Max | 1GHz |
| Number of Ports | 1 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | - |
| Shield Termination | Solder |
| Contact Termination | Solder |
| Dielectric Material | Polypropylene (PP) |
| Operating Temperature | -55°C ~ 85°C |
| Center Contact Plating | Gold |
| Center Contact Material | Phosphor Bronze |
In Stock 100 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.05 | $5.93 | $5.81 |
