Image is for reference only , See Product Specifications
ESZP22100
| Manufacturers: | Amphenol Pcd |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | ESZP22100 |
| Description: | TERM BLOCK PLUG 22POS 90DEG 5MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol Pcd |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug for Unshrouded Header |
| Color | Black |
| Pitch | 0.197" (5.00mm) |
| Series | ESZP |
| Features | - |
| Packaging | Tray |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 12A |
| Voltage - UL | 300V |
| Current - IEC | - |
| Mounting Type | Free Hanging (In-Line) |
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
| Plug Wire Entry | 90° |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.453" (11.50mm) |
| Termination Style | Screw - Rising Cage Clamp |
| Wire Strip Length | 4.06-6.10mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyamide (PA66), Nylon 6/6 |
| Number of Positions | 22 |
| Positions Per Level | 22 |
| Contact Mating Finish | Tin |
| Operating Temperature | -40°C ~ 110°C |
| Wire Gauge or Range - AWG | 14-30 AWG |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.12 | $5.02 | $4.92 |
