Image is for reference only , See Product Specifications
ELFP03410
| Manufacturers: | Amphenol Pcd |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | ELFP03410 |
| Description: | TERM BLOCK PLUG 3POS STR 7.62MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol Pcd |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Black |
| Pitch | 0.300" (7.62mm) |
| Series | ELFP |
| Features | Retention Latches (Non-Wire Side) |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 15A |
| Voltage - UL | 300V |
| Current - IEC | - |
| Mounting Type | Free Hanging (In-Line) |
| Torque - Screw | 0.79 Nm (7.0 Lb-In) |
| Plug Wire Entry | 180° |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.592" (15.04mm) |
| Termination Style | Screw - Rising Cage Clamp |
| Wire Strip Length | 7.87mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyphenylene Oxide (PPO) |
| Number of Positions | 3 |
| Positions Per Level | 3 |
| Contact Mating Finish | Tin |
| Operating Temperature | 105°C |
| Wire Gauge or Range - AWG | 12 AWG, 14-26 AWG |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 21 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.93 | $2.87 | $2.81 |
