Image is for reference only , See Product Specifications
ATB50
| Manufacturers: | Amphenol Pcd |
|---|---|
| Product Category: | Terminal Blocks - Din Rail, Channel |
| Data Sheet: | ATB50 |
| Description: | CONN TERM BLK FEED THRU 2/0-6AWG |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol Pcd |
| Product Category | Terminal Blocks - Din Rail, Channel |
| Type | Feed Through |
| Color | Gray |
| Series | ATB |
| Features | - |
| Fuse Type | - |
| Part Status | Active |
| Current - UL | 150A |
| Voltage - UL | 600V |
| Current - IEC | 150A |
| Voltage - IEC | 1000V |
| Disconnect Type | - |
| Number of Levels | 1 |
| Stripping Length | 22mm |
| Terminal - Width | 20.5mm |
| Termination Style | Screw |
| Number of Positions | 2 |
| Material - Insulation | Polyamide (PA66), Nylon 6/6 |
| Wire Gauge or Range - AWG | 2/0-6 AWG |
| Wire Gauge or Range - mm² | 16-50mm² |
| Material Flammability Rating | - |
In Stock 79 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $15.50 | $15.19 | $14.89 |
