Image is for reference only , See Product Specifications
MS3459W18-1S
| Manufacturers: | Amphenol Aerospace Operations |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | MS3459W18-1S |
| Description: | CONN PLUG FMALE 10POS GOLD CRIMP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Amphenol Aerospace Operations |
| Product Category | Circular Connectors |
| Color | Olive Drab |
| Series | Military, MIL-DTL-5015 |
| Features | Coupling Nut, Self Locking |
| Packaging | Bulk |
| Shielding | Unshielded |
| Orientation | N (Normal) |
| Part Status | Active |
| Termination | Crimp |
| Applications | Aviation, Automotive, Military |
| Shell Finish | Olive Drab Cadmium |
| Cable Opening | - |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug, Female Sockets |
| Fastening Type | Threaded |
| Shell Material | Aluminum |
| Voltage Rating | - |
| Insert Material | - |
| Shell Size, MIL | - |
| Contact Material | Copper Alloy |
| Mounting Feature | - |
| Ingress Protection | Fluid Resistant |
| Number of Positions | 10 (Power) |
| Shell Size - Insert | 18-1 |
| Current Rating (Amps) | - |
| Operating Temperature | -55°C ~ 175°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | - |
| Material Flammability Rating | - |
| Contact Finish Thickness - Mating | 50.0µin (1.27µm) |
In Stock 14 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $87.44 | $85.69 | $83.98 |
