Image is for reference only , See Product Specifications
6076C BK001
| Manufacturers: | Alpha Wire |
|---|---|
| Product Category: | Multiple Conductor Cables |
| Data Sheet: | 6076C BK001 |
| Description: | MULTI-PAIR 12COND 24AWG 1000' |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Alpha Wire |
| Product Category | Multiple Conductor Cables |
| Usage | - |
| Length | 1000.0' (304.8m) |
| Series | - |
| Ratings | UL Style 2493 |
| Voltage | 300V |
| Features | Drain Wire |
| Cable Type | Multi-Pair |
| Wire Gauge | 24 AWG |
| Part Status | Active |
| Shield Type | Foil |
| Jacket Color | Black |
| Shield Coverage | 100% |
| Shield Material | Aluminum |
| Conductor Strand | 7/32 |
| Conductor Material | Copper, Tinned |
| Conductor Insulation | Foam Polypropylene (FPP) |
| Number of Conductors | 12 (6 Pair Twisted) |
| Operating Temperature | -20°C ~ 75°C |
| Jacket (Insulation) Diameter | 0.483" (12.27mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.0480" (1.219mm) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2,849.42 | $2,792.43 | $2,736.58 |
