Image is for reference only , See Product Specifications
5561C SL001
| Manufacturers: | Alpha Wire |
|---|---|
| Product Category: | Multiple Conductor Cables |
| Data Sheet: | 5561C SL001 |
| Description: | CABLE 7COND 20AWG SHLD 1000' |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Alpha Wire |
| Product Category | Multiple Conductor Cables |
| Usage | - |
| Length | 1000.0' (304.8m) |
| Series | Xtra-Guard® 1 |
| Ratings | UL Style 21895 |
| Voltage | 300V |
| Features | Drain Wire, Rip Cord |
| Cable Type | Multi-Conductor |
| Wire Gauge | 20 AWG |
| Part Status | Active |
| Shield Type | Foil, Braid |
| Jacket Color | Slate |
| Shield Coverage | 100%, 70% |
| Shield Material | Aluminum; Copper, Tinned |
| Conductor Strand | 7/28 |
| Conductor Material | Copper, Tinned |
| Conductor Insulation | Poly-Vinyl Chloride (PVC) |
| Number of Conductors | 7 |
| Operating Temperature | -30°C ~ 105°C |
| Jacket (Insulation) Diameter | 0.309" (7.85mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.0630" (1.600mm) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6,630.83 | $6,498.21 | $6,368.25 |
Request Quote
