Image is for reference only , See Product Specifications
ADS15A-KG-TAXB5
| Manufacturers: | ASSMANN WSW Components |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | ADS15A-KG-TAXB5 |
| Description: | CONN D-SUB PLUG 15POS R/A SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | ASSMANN WSW Components |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | - |
| Features | Board Lock, Grounding Indents |
| Packaging | Tray |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Through Hole, Right Angle |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (4-40) |
| Number of Rows | 2 |
| Voltage Rating | - |
| Backset Spacing | 0.590" (14.99mm) |
| Connector Style | D-Sub |
| Contact Material | Copper Alloy |
| Ingress Protection | - |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Number of Positions | 15 |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 105°C |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 2 (DA, A) |
In Stock 4 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.43 | $3.36 | $3.29 |
