Image is for reference only , See Product Specifications
S4924-226K
| Manufacturers: | API Delevan Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | S4924-226K |
| Description: | FIXED IND 22MH 37MA 274 OHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | API Delevan Inc. |
| Product Category | Fixed Inductors |
| Type | - |
| Series | S4924 |
| Ratings | - |
| Q @ Freq | 27 @ 79kHz |
| Packaging | Tape & Reel (TR) |
| Shielding | Shielded |
| Tolerance | ±10% |
| Inductance | 22mH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Size / Dimension | 0.505" L x 0.240" W (12.82mm x 6.09mm) |
| DC Resistance (DCR) | 274Ohm Max |
| Current - Saturation | 7mA |
| Current Rating (Amps) | 37mA |
| Height - Seated (Max) | 0.220" (5.58mm) |
| Operating Temperature | -55°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 500kHz |
| Inductance Frequency - Test | 79kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.98 | $2.92 | $2.86 |
