Image is for reference only , See Product Specifications
HCTR-504
| Manufacturers: | API Delevan Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | HCTR-504 |
| Description: | FIXED IND 17UH 5.37A 17 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | API Delevan Inc. |
| Product Category | Fixed Inductors |
| Type | Toroidal |
| Series | HCTR |
| Ratings | - |
| Q @ Freq | 22 @ 100kHz |
| Packaging | Bulk |
| Shielding | Shielded |
| Tolerance | ±25% |
| Inductance | 17µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Iron Powder |
| Size / Dimension | 0.740" L x 0.740" W (18.80mm x 18.80mm) |
| DC Resistance (DCR) | 17mOhm Max |
| Current - Saturation | - |
| Current Rating (Amps) | 5.37A |
| Height - Seated (Max) | 0.400" (10.16mm) |
| Operating Temperature | -30°C ~ 130°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 29MHz |
| Inductance Frequency - Test | 100kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.39 | $4.30 | $4.22 |
