Image is for reference only , See Product Specifications
5HCR-250
| Manufacturers: | API Delevan Inc. |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | 5HCR-250 |
| Description: | FIXED IND 250UH 5A 75 MOHM TH |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | API Delevan Inc. |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | HCR |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Bulk |
| Shielding | Unshielded |
| Tolerance | ±10% |
| Inductance | 250µH |
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | Radial, Horizontal Cylinder (Open) |
| Material - Core | Ferrite |
| Size / Dimension | 1.100" Dia x 1.625" L (27.94mm x 41.28mm) |
| DC Resistance (DCR) | 75mOhm Max |
| Current - Saturation | 3A |
| Current Rating (Amps) | 5A |
| Height - Seated (Max) | - |
| Operating Temperature | - |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 1kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $15.95 | $15.63 | $15.32 |
Request Quote
