Image is for reference only , See Product Specifications
P65THR701
| Manufacturers: | APEM Inc. |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | P65THR701 |
| Description: | SWITCH ROTARY DIP BCD 200MA 50V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | APEM Inc. |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.393" (10.00mm) |
| Series | P65 |
| Circuit | BCD |
| Features | - |
| Washable | Yes |
| Packaging | Tube |
| Part Status | Active |
| Actuator Type | Rotary for Tool |
| Body Material | Thermoplastic |
| Mounting Type | Through Hole |
| Actuator Level | Raised |
| Contact Finish | Gold |
| Voltage Rating | 50VDC |
| Electrical Life | - |
| Mechanical Life | 30,000 Cycles |
| Contact Material | Copper Alloy |
| Termination Style | PC Pin |
| Height Above Board | 0.256" (6.50mm) |
| Number of Positions | 10 |
| Current Rating (Amps) | 200mA |
| Operating Temperature | -60°C ~ 125°C |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.24 | $5.14 | $5.03 |
