GH39S010001
| Manufacturers: | APEM Inc. |
|---|---|
| Product Category: | Slide Switches |
| Data Sheet: | GH39S010001 |
| Description: | SWITCH SLIDE SPDT 3A 30V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | APEM Inc. |
| Product Category | Slide Switches |
| Series | G |
| Circuit | SPDT |
| Features | Epoxy Sealed Terminals |
| Packaging | Bulk |
| Part Status | Active |
| Actuator Type | Standard |
| Mounting Type | Panel Mount |
| Switch Travel | 2.20mm |
| Contact Finish | - |
| Contact Timing | Not Specified |
| Actuator Length | 5.10mm |
| Electrical Life | 20,000 Cycles |
| Mechanical Life | - |
| Operating Force | - |
| Switch Function | On-Off-On |
| Contact Material | Silver (Ag) |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled |
| Termination Style | Solder Lug |
| Voltage Rating - DC | 30V |
| Current Rating (Amps) | 3A (DC) |
| Operating Temperature | -30°C ~ 85°C |
In Stock 173 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.41 | $5.30 | $5.20 |
