Image is for reference only , See Product Specifications
MVU18-8FLK
| Manufacturers: | 3M |
|---|---|
| Product Category: | Terminals - Spade Connectors |
| Data Sheet: | MVU18-8FLK |
| Description: | CONN SPADE TERM 18-22AWG #8 RED |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | 3M |
| Product Category | Terminals - Spade Connectors |
| Color | Red |
| Series | Scotchlok™ |
| Features | Butted Seam |
| Packaging | Bulk |
| Insulation | Insulated |
| Wire Gauge | 18-22 AWG |
| Part Status | Active |
| Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 8 Stud |
| Terminal Type | Spring, Snap |
| Contact Finish | Tin |
| Contact Material | Copper, ETP |
| Length - Overall | 0.880" (22.35mm) |
| Insulation Diameter | 0.145" (3.68mm) |
| Width - Outer Edges | 0.300" (7.62mm) |
| Length - Termination | 0.450" (11.43mm) |
| Material - Insulation | Vinyl |
| Tongue Inside Opening | - |
| Length - Ring Center to Termination | 0.250" (6.35mm) |
In Stock 5779 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.50 | $0.49 | $0.48 |
