Image is for reference only , See Product Specifications
MV14-8FX-BOTTLE
| Manufacturers: | 3M |
|---|---|
| Product Category: | Terminals - Spade Connectors |
| Data Sheet: | MV14-8FX-BOTTLE |
| Description: | CONN SPADE TERM 14-16AWG #8 BLU |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | 3M |
| Product Category | Terminals - Spade Connectors |
| Color | Blue |
| Series | Scotchlok™ |
| Features | Brazed Seam |
| Packaging | Bulk |
| Insulation | Insulated |
| Wire Gauge | 14-16 AWG |
| Part Status | Active |
| Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 8 Stud |
| Terminal Type | Standard |
| Contact Finish | Tin |
| Contact Material | Copper, ETP |
| Length - Overall | 0.900" (22.86mm) |
| Insulation Diameter | 0.170" (4.32mm) |
| Width - Outer Edges | 0.340" (8.64mm) |
| Length - Termination | 0.450" (11.43mm) |
| Material - Insulation | Vinyl |
| Tongue Inside Opening | - |
| Length - Ring Center to Termination | 0.290" (7.37mm) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $65.01 | $63.71 | $62.44 |
